Table 4. Vehicle Performance. - Continued
Turning Radius (HET Tractor Only): 67.9 ft. (20.7 m)
Turning Radius (HET System = HET Tractor + M1000 Trailer): 78.8 to 81 ft. (24.03 to
24.7 m)
Table 5. Fluid Capacities.
Refer to lubrication instructions (WP 0106) in operator's PMCS for vehicle fluid capacities.
Table 6. Engine.
Make: Detroit Diesel Corporation
Model: 8V92TA DDEC II or III/IV
Type: 2-Stroke, V-Type Diesel, Turbocharged, Aftercooled
Cylinders: 8
Bore: 4.84 in. (123 mm)
Stroke: 5 in. (127 mm)
Displacement: 736 cid (12.1 L)
Torque (at 2100 rpm): 1470 lb-ft (1 993 N·m)
Maximum Brake Horsepower (at 2100 rpm): 500 BHP (373 kW)
Maximum Governed Engine Speed (Loaded): 2050 - 2150 rpm
Oil Filter Type: Full Flow, Replaceable Element
Oil Filter Quantity: 1
Table 7. Fuel System.
Type: Electronic Diesel Injection
Tank Quantity: 2
TM 9-2320-360-10 0005
0005-3
