Table 26. Auxiliary Winch. - Continued
Cable Dimensions: .25 in. (6.4 mm) diameter X 300 ft. (91.5 m) length
Table 27. Wheels.
Make: Titan
Rim Size: 20 x 10
Type: Two-piece bolt together wheel
Quantity: 9 (including spare)
Stud Quantity Per Wheel: 10
Maximum Wheel Load: 12,500 lbs (5 675 kg)
Table 28. Central Tire Inflation System (CTIS).
Make: CM Automotive
Table 29. Tires.
Make: Michelin
Size: 425/95 R20 (16.00 R20)
Tread Design: Non-Directional, On-Off Road
Ply Rating: 22 Ply
Type: Tubeless/Radial
Load Range: M
Per Tire Load (HET Tractor Unloaded)
Front: 9,184 lbs (4 170 kg)
Rear: 3,772 lbs (1 712 kg)
Per Tire Load (HET Tractor at GVWR)
TM 9-2320-360-10 0005
0005-10
