Table 1. Main Instrument Panel Controls and Indicators. - Continued
Key
Control/
Indicator Function
18 Speedometer/
Odometer
Shows tractor traveling speed (in mph and km/h) and total
miles traveled.
19 BATTERY
Gauge (12-volt
system)
Shows state of charge of batteries and alternator voltage
output. During normal operations, range is 13 to 15 volts.
20 BATTERY
Gauge (24-volt
system)
Shows state of charge of batteries and alternator voltage
output. During normal operations, range is twice the 12-volt
system voltage, +/- 1 volt (26 to 30 volts).
21 All Wheel Drive
Indicator
Lights (green) when DRIVELINE control is set to LOCK
position or when TRANSFER CASE shift lever is set to LOW
position.
22 Right Turn
Indicator
Flashes (green) when turn signal is on.
23 Beacon Light
Switch
Two-position switch used to control rotating beacon light.
Push beacon light switch up to turn light off and down to turn
light on.
24 Work Light
Switch
Two-position switch used to control work light.
25 Dome Light
Switch
Two-position switch used to control dome light.
26 Headlights
Switch
Three-position switch used to control headlights, clearance
lights, and parking lights. BLACK OUT LIGHTS switch must
be set to off position before headlights will operate.
TM 9-2320-360-10 0015
0015-5
