SWINGFIRE ARCTIC HEATER SHUTDOWN - Continued
4. Remove cable (5) from vehicle receptacle (7).
10
9
8
2
5
7
11
Figure 6.
WARNING
Heater is very hot and can burn. Handle heater carefully. Failure to
comply may result in serious injury or death to personnel.
5. Loosen wing nut (8) on heater (2) and clamp (9).
6. Remove heater (2) from water jacket (10).
7. Install cap (11) on water jacket (10).
END OF TASK
END OF WORK PACKAGE
TM 9-2320-360-10 0044
0044-6
