SPARE TIRE REMOVAL - Continued
5
12
1
Figure 5.
10. With assistant pulling spare tire away from bracket (12), turn handcrank (1) to lower
spare tire assembly (5) to ground.
WARNING
Do not remove cable at this time. Tire could fall over. Failure to comply
may result in serious injury or death to personnel.
11. With the aid of an assistant, lean spare tire assembly (5) against HET Tractor.
END OF TASK
FLAT TIRE REMOVAL
WARNING
Never go under equipment when supported only by jack. Keep clear of
equipment when raising or lowering. Failure to comply may result in
serious injury or death to personnel.
TM 9-2320-360-10 0108
0108-8
