SPARE TIRE INSTALLATION - Continued
WARNING
Tire assembly is very heavy. Do not try to lift or catch tire assembly.
Failure to comply may result in serious injury or death to personnel.
5. With the aid of an assistant, lean top of spare tire assembly (2) against hub (7) and
axle (3).
WARNING
Use caution when operating jack. Personal injury or death may result if
jack slips out from under HET Tractor.
WARNING
Never go under HET Tractor with engine running. HET Tractor may move
unexpectedly. Failure to comply may result in serious injury or death to
personnel.
CAUTION
Use care when installing spare tire assembly and nuts. Dragging tire
assembly across studs or cross-threading nuts may result in damage to
studs.
NOTE
It may be necessary to raise jack to get inflated spare tire on wheel hub.
6. Slide spare tire assembly (2) onto studs (9) with tire extension handle (WP 0114,
Table 3, Item 17). Bottom of spare tire assembly (2) should swing toward HET Tractor.
