OPERATOR MAINTENANCE
LOCATION AND DESCRIPTION OF MAJOR COMPONENTS
Major components and accessories found on the M1070 HET Tractor are illustrated and
described below.
Table 1. Location and Description of Major Components.
3
1
2
7
5
4
6
Figure 1.
1
HOOD. Houses engine and components.
TM 9-2320-360-10 0004
0004-1
