USER'S MANUAL
General instructions for use
I-Max Touch (110-120V) (Rev. 0)
116
NOTE:
In some cases, the positioning of the Frankfurt plane too tilted downward
produces a correct image of the lower incisors, but the projection of the
palate falls on the upper teeth apex, as shown in Figure 26.
Figure 26
In this case, a light tilting forward and downward of the Frankfurt plane
causes the palate to be projected over and far enough from the roots of
the teeth of the maxillary arch, without distortion of the incisor teeth, as
in Figure 27.
Figure 27
*
