Technical characteristics
I-Max Touch (110-120V) (Rev. 0)
16
Image magnification
Standard Panoramic
Constant over dentition part:
1 : 1.23 Adult - 1 : 1.25 Child
TMJ open/closed mouth, 4 images 1 : 1.20 (nominal)
Sinus 1 : 1.22 (nominal)
Ceph
1 : 1.10 (on the sagittal medial plane in
LL projection)
Tube-head characteristics
Model MRE 05
Manufacturer
Villa Sistemi Medicali S.p.A.
20090 Buccinasco (MI) Italia
Maximum tube voltage 86 kV
p
kV
p
accuracy ± 8 %
Maximum anodic current 12 mA
Anodic current accuracy ± 10 %
Duty cycle 1 : 16
Nominal power 1.032 kW (86 kV
p
- 12 mA)
Total filtration 2.5 mm Al eq. @ 70 kV
p
HVL (Half value layer) > 3.1 mm Al eq. @ 86 kV
p
Transformer insulation Oil bath
Cooling By convection
Leakage radiation at 1 m
< 0.5 mGy/h @ 86 kV
p
- 12 mA - 3 s duty
cycle 1/16
Tube-head maximum thermic capacity 310 kJ
X-ray tube characteristics
Manufacturer CEI Bologna (Italy)
Type OPX 105
Nominal focus size 0.5 IEC 60336
Inherent filtration 0.5 mm Al eq.
Anode tilt 5°
Anode material Tungsten
Nominal maximum voltage 105 kV
p
Filament max current 4 A
Filament max voltage 8 V
Anode thermal capacity 30 kJ
