USER'S MANUAL
Technical characteristics
(Rev. 0) I-Max Touch (110-120V)
17
Digital Sensor
Sensible area (H x L)
• PAN sensor: 146 x 6 mm
• PANCEPH sensor: 220 x 6 mm
Pixel dimensions
48 µm, 96 µm in binning 2x2 (PAN and
PANCEPH HR), 144 µm CEPH nR
Pixel (H)
NOTE:
Number of horizontal pixels depends on
the exam and resolution on CEPH.
• PAN: 1536
• CEPH: 1536 in nR, 2304 in HR
Laser centring devices
2 laser beams are used for the patient positioning; beams align mid Sagittal and
Frankfurt planes (please refer to relevant paragraphs for detailed explanation).
Wave length 650 nm
Divergence 12.5 mRad
Optical power on the working surface < 0.5 mW
Laser class Class 1 according to IEC 60825-1+A1+A2
DNRO in 30s application period 0.05m
Mechanical characteristics
Focus-receptor distance (PAN, TMJ and
Sinus)
50 cm (19.7")
Focus-receptor distance (CEPH) 165 cm (65")
Telescopic motorised column run 85 cm (33.5")
Maximum total height 245 cm (96.5")
Weight
• 161 kg (354 lbs) base version
• 186 kg (409 lbs) version with Ceph
Column weight 87 kg (192 lbs)
Weight of arm support, rotating arm and
tube head
74 kg (163 lbs)
CEPH arm 25 kg (55 lbs)
Legs (optional) 30 kg (66 lbs)
Sensor holder weight 2 kg (5 lbs)
