MS Series User Guide
17
2. From the tile, select a sub-tab (Port>Port Summary), then click the More ( ) icon.
a. To edit, click the More ( ) icon and click Edit.
b. To add, click the More ( ) icon and click Add.
3. Make any adjustments, then click Continue.
4. Click Apply to save and apply your changes.
Important! Your changes will not be saved until you click Apply.
Completing the dialog
Depending on the selected interface, you will see different editing options. See below for a
summary of each tile.
Tiles
• Port: Manage the port summary and port details.
• VLAN: Manage the VLAN database, switchport configurations, or reset the VLAN.
• PoE: Manage PoE settings: Port Configuration, General, Statistics, and Details.
