Reset using the physical RESET button
Your switch has a recessed RESET button accessible through a pinhole next to the Ethernet
port underneath the switch.
To only reboot the switch, maintaining all settings:
1. While power is connected, insert a narrow, pointed object (such as a straightened
paper clip) into the hole.
2. Press and release the button.
To reset to factory default settings, deleting all user settings:
Caution: Performing this reset will delete all of your settings on the switch.
1. While power is connected, insert a narrow, pointed object (such as a straightened
paper clip) into the hole.
2. Press and hold the button for at least ten seconds, then release it.
Advanced
From the Advanced tab, perform advanced tasks.
Perform maintenance, view statistics, and configure settings for various services and
protocols.
Below is a summary of each feature available on the Advanced tab.
Advanced feature
Summary
IGMP Snooping
Manage, configure, and monitor IGMP Snooping settings per VLAN interface.
IGMP Snooping Querier
Manage, configure, and monitor IGMP Snooping Querier settings.
Set the query interval, configure VLAN query settings, and view VLAN status.
Unregistered Multicast
Behavior
Configure the behavior of Unregistered multicast traffic when IGMP Snooping is
enabled.
Allows for exception rules to be created allowing some multicast
groups to continue to flood while
the rest are set to Drop.
Spanning Tree Protocol
Manage, configure, and monitor STP activity for MST, MST Ports, and CST
Ports
.
IP IGMP
Allows ports to be configured as a dedicated network for IGMP Snooping. Ports
become a routable interface with a dedicated IP address and IGMP Snooping is
isolated to
the individual port and the network below that port.
IP Multicast
Configure IP Multicast Routing using Protocol-Independent Multicast – Sparse
Mode (PIM
-SM) to make the switch act as a multicast router for the network.
IP Multicast
Information
Monitor IP Multicast Routing Information for Elected Bootstrap Router,
Rendezvous Point Mapping, and Multicast Route Table.
Firmware
Update the switch firmware for functionality improvements and feature
enhancements.
