Pakedge MS Series User Manual

MS Series User Guide
55
Designated Root
The bridge ID of the root bridge for the CST.
Designated Cost
The path cost offered to the LAN by the designated port.
Designated Bridge
The bridge ID of the bridge with the designated port.
Designated Port
The port ID of the designated port.
Topology Change
Acknowledge
Indicates whether the next BPDU to be transmitted for this port will
have the topology change acknowledgment flag set.
Edge Port
Indicates whether the interface is configured as an edge port
(Enabled).
Point-to-point MAC
Indicates whether the link type for the interface is a point-to-point
link.
CST Regional Root
The bridge ID of the bridge that has been elected as the root bridge
of the CST region.
CST Path Cost
The path cost from the interface to the CST regional root.
Loop Inconsistent
State
Identifies whether the interface is currently in a loop-inconsistent
state. An interface transitions to a loop-inconsistent state if Loop
Guard is enabled and the port stops receiving BPDUs. In this state,
the interface does not transmit frames.
Transitions Into
LoopInconsistent
State
The number of times this interface has transitioned into loop
inconsistent state.
Transitions Out Of
LoopInconsistent
State
The number of times this interface has transitioned out of loop
inconsistent state.
MST Configuration
Use the MST Configuration page to view and configure the Multiple Spanning Tree Instances
(MSTIs) on the device. Multiple Spanning Tree Protocol (MSTP) allows the creation of MSTIs
based upon a VLAN or groups of VLANs. Configuring MSTIs creates an active topology with a
better distribution of network traffic and an increase in available bandwidth when compared
to classic STP.
1. In the Spanning Tree screen, click the MST tab.
The Spanning Tree MST screen opens.
