MS Series User Guide
31
Edit PoE General Settings
To adjust a setting on the General sub-tab:
1. Go to Interfaces > PoE > General.
2. Complete the fields.
3. To save your changes, click Apply.
Explanations: PoE General setting
Title
Function
Operational Status
The current status of the switch PoE functionality.
Total Power Available
The total power in mW that can be provided by the switch.
Threshold Power
This value is determined by the configurable System Usage
Threshold
percent.
Consumed Power
The amount of power in mW currently being consumed by
connected PoE devices.
System Usage Threshold (%)
Click to type.
A percentage of the total power available. This percentage
determines the Threshold Power. The Threshold Power is the
maximum amount of the PoE power budget that will be allocated
from the switch.
Power Management Mode
Select Static or Dynamic.
The method by which the PoE controller determines supplied
power.
Port Auto Reset Mode
Select/unselect.
Select/Unselect Auto Reset Mode.
Traps
Slide to enable/disable.
Enable/Disable traps.
Statistics (read only)
To access PoE statistics, go to Interfaces > PoE > Statistics .
