Pakedge MS Series User Manual

MS Series User Guide
6
Getting to know your switch
This manual outlines the steps for configuring the web user interface settings for the Pakedge
MS Series and can be used for the following products: MS-1212, MS-2400, MS-2416, MS-2424,
and MS-4424.
Package contents:
• Switch
• AC adapter
• Ethernet cable
• Rack mount set
• Quick Start Guide
Front panel
LED Type
LED Color
LED Definition
Power LED
Blue
• Solid Blue: Device is on
• Flicker Blue: Device is booting
• Off: Device is off
PoE/Ethernet port LED
Blue/Amber
•
Solid Blue: No Data is Transmitting
• Flicker Blue: Data is Transmitting
• Off: Link Down
• Solid Amber: PoE is Powering, No Data is Transmitting
• Flicker Amber: PoE is Powering and Data is Transmitting
SFP Port LED
Blue
• Solid Blue: No Data is Transmitting
•
Flicker Blue:
Data is Transmitting
• Off: Link Down
