RT-3100 5-Port Single-WAN Gigabit Router User Guide
Field Description Example
Description
Give the schedule a descriptive name. Kids’ Internet
Client
Devices
Click the Clients field. Select the devices
that should be included in the schedule; or
manually type in the IP address for a
specific device.
192.168.1.135
Protocols
The Protocol field allows you to select
whether you want to block TCP, UDP or
both for this policy.
l TCP+UDP
l TCP
l UDP
Ports
The Ports field allows you to specify which
port you wish to block from going out to
the internet. For example, you can type in
port 80 and that would deny any traffic
that is using that port from going out to
the internet.
Note: You can
block a device
from completely
accessing the
internet. To do this,
leave both the
Protocol and Ports
fields blank.
Time
Range
Choose the times internet will be available
for the selected devices.
6:30 am – 10:30 pm
Days
Choose the days internet will be available
for selected devices.
M, T, W, Th, F, S, Su
All
Weekdays
Weekends
Continue
Continue temporarily saves the schedule.
Click Apply (at the top of the page) to
activate the schedule.
