Chapter 4. Trunks and Lines Section 300-Installation
4-34 DBS Manual - Revised April 2000 DBS-2.3/9.2-300
Table 4-21. Pinouts and color codes for extension connector CN13
Extension Slot Color Code Pin No. Desig. Function
EC4
(DBS 72,
DBS 96)
WH-BL
BL-WH
26
1
1T
1R
Extension Port 25
WH-OR
OR-WH
27
2
2T
2R
Extension Port 26
WH-GN
GN-WH
28
3
3T
3R
Extension Port 27
WH-BR
BR-WH
29
4
4T
4R
Extension Port 28
WH-SL
SL-WH
30
5
5T
5R
Extension Port 29
RD-BL
BL-RD
31
6
6T
6R
Extension Port 30
RD-OR
OR-RD
32
7
7T
7R
Extension Port 31
RD-GN
GN-RD
33
8
8T
8R
Extension Port 32
EC5
(DBS 72,
DBS 96)
RD-BR
BR-RD
34
9
9T
9R
Extension Port 33
RD-SL
SL-RD
35
10
10T
10R
Extension Port 34
BK-BL
BL-BK
36
11
11T
11R
Extension Port 35
BK-OR
OR-BK
37
12
12T
12R
Extension Port 36
BK-GN
GN-BK
38
13
13T
13R
Extension Port 37
BK-BR
BR-BK
39
14
14T
14R
Extension Port 38
BK-SL
SL-BK
40
15
15T
15R
Extension Port 39
YL-BL
BL-YL
41
16
16T
16R
Extension Port 40
EC6
(DBS 72,
DBS 96)
YL-OR
OR-YL
42
17
17T
17R
Extension Port 41
YL-GN
GN-YL
43
18
18T
18R
Extension Port 42
YL-BR
BR-YL
44
19
19T
19R
Extension Port 43
YL-SL
SL-YL
45
20
20T
20R
Extension Port 44
VI-BL
BL-VI
46
21
21T
21R
Extension Port 45
VI-OR
OR-VI
47
22
22T
22R
Extension Port 46
VI-GN
GN-VI
48
23
23T
23R
Extension Port 47
VI-BR
BR-VI
49
24
24T
24R
Extension Port 48
VI-SL
SL-VI
50
25
Not used
