Section 300-Installation Chapter 4. Trunks and Lines
DBS-2.3/9.2-300 DBS Manual - Revised April 2000 4-35
Table 4-22. Pinouts and color codes for extension connector CN14
Note:
The EC/TRK slot is wired to CN14 only in the DBS 96. In the DBS 40 and
72, a card placed in the EC/TRK slot must be wired to the expansion connector.
Extension Slot Color Code Pin No. Desig. Function
EC7
(DBS 96 Only)
WH-BL
BL-WH
26
1
1T
1R
Extension Port 49
WH-OR
OR-WH
27
2
2T
2R
Extension Port 50
WH-GN
GN-WH
28
3
3T
3R
Extension Port 51
WH-BR
BR-WH
29
4
4T
4R
Extension Port 52
WH-SL
SL-WH
30
5
5T
5R
Extension Port 53
RD-BL
BL-RD
31
6
6T
6R
Extension Port 54
RD-OR
OR-RD
32
7
7T
7R
Extension Port 55
RD-GN
GN-RD
33
8
8T
8R
Extension Port 56
EC8
(DBS 96 Only)
RD-BR
BR-RD
34
9
9T
9R
Extension Port 57
RD-SL
SL-RD
35
10
10T
10R
Extension Port 58
BK-BL
BL-BK
36
11
11T
11R
Extension Port 59
BK-OR
OR-BK
37
12
12T
12R
Extension Port 60
BK-GN
GN-BK
38
13
13T
13R
Extension Port 61
BK-BR
BR-BK
39
14
14T
14R
Extension Port 62
BK-SL
SL-BK
40
15
15T
15R
Extension Port 63
YL-BL
BL-YL
41
16
16T
16R
Extension Port 64
EC/TRK
(DBS 96 only)
YL-OR
OR-YL
42
17
17T
17R
Extension Port 65
YL-GN
GN-YL
43
18
18T
18R
Extension Port 66
YL-BR
BR-YL
44
19
19T
19R
Extension Port 67
YL-SL
SL-YL
45
20
20T
20R
Extension Port 68
VI-BL
BL-VI
46
21
21T
21R
Extension Port 69
VI-OR
OR-VI
47
22
22T
22R
Extension Port 70
VI-GN
GN-VI
48
23
23T
23R
Extension Port 71
VI-BR
BR-VI
49
24
24T
24R
Extension Port 72
VI-SL
SL-VI
50
25
Not used
