Communication cassette LED indication
The indication of the control unit is for 2-channel RS232C type. For the other types, refer to the following.
Indication of
control unit
AFPG801 AFPG802 AFPG803 AFPG806
SD SD SD
RS485
SD
RD RD RD
RS485
RD
RS SD Not used
RS232C
SD
CS RD Not used
RS232C
RD
LED Communicating: Flashes
No communication: Lights out
SD: Sent data (output)
RD: Received data (input)
Difference of dimensions
AFPG801 AFPG806
AFPG802 Note) This is longer by 5mm.
AFPG803
