No. Name
Default
value
Descriptions
CH0:
Do not set
input X0
as high-
speed
counter
CH0
Do not set input X0 as high-speed counter.
Two-phase input (X0, X1)
Two-phase input (X0, X1), Reset input (X2)
Incremental input (X0)
Incremental input (X0), Reset input (X2)
Decremental input (X0)
Decremental input (X0), Reset input (X2)
incremental/decremental input (X0, X1)
incremental/decremental input (X0, X1),
Reset input (X2)
Incremental/decremental control input (X0,
X1)
Incremental/decremental control input (X0,
X1), Reset input (X2)
400
High-speed counter
operation mode
settings (X0 to X2)
CH1:
Do not set
input X1
as high-
speed
counter
CH1
Do not set input X1 as high-speed counter.
Incremental input (X1)
Incremental inptu (X1), Reset input (X2)
Decremental input (X1)
Decremental input (X1), Reset input (X2)
CH2:
Do not set
input X3
as high-
speed
counter
CH2
Do not set input X3 as high-speed counter.
Two-phase input (X3, X4)
Two-phase input (X3, X4), Reset input (X5)
Incremental input (X3)
Incremental input (X3), Reset input (X5)
Decremental input (X5)
Decremental input (X5), Reset input (X5)
Incremental/decremental input (X3, X4)
Incremental/decremental input (X3, X4),
Reset input (X5)
Incremental/decremental control
(X3, X4)
Incremental/decremental control
(X3, X4), Reset input (X5)
High-
speed
coun-
ter
401
High-speed counter
operation mode
settings (X3 to X5)
HC3:
Does not
set input
X4 as
high-
speed
counter
CH3
Does not set input X4 as high-speed
counter.
Incremental input (X4)
Incremental input (X4), Reset input (X5)
Decremental input (X4)
Decremental input (X4), Reset input (X5)
