Panasonic FP Series Technical Manual

FP Modem-EU Technical Manual
3.8 ASCII-Fax Function
modem starts dialing the stored number.
The converting can take some time (about 30 seconds to 1 minute). If the fax has
been sent successfully, you receive the hang-up message (class2) and OK or
ERROR as a response. If the fax could not be sent, there is no automatic repetition.
A new attempt has to be initiated by the PLC.
Please use the FPWIN Pro Library "Modem" for PLC programming support.
3.8.1 Fax Characters (HEX)
The following set of characters is implemented. Characters that are not included in this set of
characters are replaced by a space.
0x20 – 0x2F
!,",#,$,%,&,’,(,),*,+,,,-,.,/
0x30 – 0x3F
0,1,2,3,4,5,6,7,8,9,:,;,<,=,>,?
0x40 – 0x4F
@,A,B,C,D,E,F,G,H,I,J,K,L,M,N,O
0x50 – 0x5F
P,Q,R,S,T,U,V,W,X,Y,Z,Ä,Ö,Ü,ß,_
0x60 – 0x6F
’,a,b,c,d,e,f,g,h,i,j,k,l,m,n,o
0x70 - 0x7F
p,q,r,s,t,u,v,w,x,y,z,ä,ö,ü,~
For special characters, e.g. umlauts, you have to use special fax characters, depending on
whether you are working with a Windows or a DOS operating system:
Umlaut Windows DOS
ä
0xE4 0x84
ö
0xF6 0x94
ü
0xFC 0x81
Ä
0xC4 0x8E
Ö
0xD6 0x99
Ü
0xDC 0x9A
ß
0xDF 0xE1
43

Panasonic FP Series Specifications

General

Mounting	DIN rail
Type	PLC
Communication Interface	RS-232, RS-485, Ethernet (depending on model)
Input Voltage	100-240V AC or 24V DC (depending on model)
Output Type	Relay, Transistor
I/O Points	Varies by model
Operating Temperature	0°C to 55°C
Dimensions	Varies by model
Weight	Varies by model
