Panasonic FP Series Technical Manual

Hardware Installation
FP Modem-EU Technical Manual
2.4 Technical Data
Generalities
Dimensions
Height 90 mm, Width 25 mm, Depth 64 mm
Connection to the telephone
network
RJ12 jack and RJ12-RJ12 cable
(The cable is supplied with the FP Modem-EU.)
Carrier detect connection
3-pin Phoenix screw terminal port plug
RS232C port
9-pin SUB-D female plug on the front side
Power Supply
24V DC Molex35 plug on the bottom side of the unit
LEDs
Power, DCD on the front side
Environmental requirements
Ambient temperature
0 - 55°C
Humidity
5 – 95% non-condensing
Storage temperature
-20 ... +70°C
Vibration resistance
10 - 55Hz, 1 cycle/min.: double amplitude of 0.75mm, 10min on 3 axes
Shock resistance
min. 10g; 4 times every X-, Y-, and Z-axis
Electrical specifications
Operating voltage
24V DC (16,6 – 26,4V DC)
Current consumption
Approx. 90mA / max. 120mA
Telephone jack
RJ12 jack 4-pin
Signal level of the telephone
connection
-12d Bm/-10d Bm (dialing operation)
Surge protection
Varistor for long-distance lines, deflection via Molex plug (FG)
Modem specifications
Equalization
Transmit fixed compromise, receive automatic adaptive
Interface
ZR
Error correction
V.42, LAPM, MNP4
Data compression
V.42bis and MNP5
Dialing method
Pulse dialing, tone dialing (DTMF)
Call control
Extended AT command set
Mode selection
Automatic configuration of V.21/V.22/ V.23/V.22bis/V.32/V.32bis
RS232C baud rate
600, 1200, 2400, 4800, 9600, 14400, 19200, 38400, 57600, 115200 bps
Test mode
Self-diagnostic function
Line transmission speed
14400 bps
Up to 57600 bps with V.32bis and V.42bis data compression (depending on the
type of data)
14

Panasonic FP Series Specifications

General

Mounting	DIN rail
Type	PLC
Communication Interface	RS-232, RS-485, Ethernet (depending on model)
Input Voltage	100-240V AC or 24V DC (depending on model)
Output Type	Relay, Transistor
I/O Points	Varies by model
Operating Temperature	0°C to 55°C
Dimensions	Varies by model
Weight	Varies by model
