Panasonic FP Series Technical Manual

Remote Networking with Windows
FP Modem-EU Technical Manual
9. Please also remember to enter your user name and password in the Config
tab
Wiring of the FP Modem-EU and the FP Web-Server
1. Make sure that all DIP switches of the FP Modem-EU are set to OFF (default
setting)
2. Use a standard modem cable as described in the online help of the Control
FP WEB Configurator Tool
3. Connect the 9-pin port of the FP Web-Server to the 9-pin port of the FP
Modem-EU
4. Use the same power supply for the FP Web-Server and for the FP Modem-EU
84

Panasonic FP Series Specifications

General

Mounting	DIN rail
Type	PLC
Communication Interface	RS-232, RS-485, Ethernet (depending on model)
Input Voltage	100-240V AC or 24V DC (depending on model)
Output Type	Relay, Transistor
I/O Points	Varies by model
Operating Temperature	0°C to 55°C
Dimensions	Varies by model
Weight	Varies by model
