Insulation, Dielectric Strength
Circuit insulation
configuration
KT4R
KT8R, KT9R
Insulation resistance: 10 M or more, at 500 V DC
Dielectric strength
Between input terminal and power terminal: 1.5 kV AC for 1 minute
Between output terminal and power terminal: 1.5 kV AC for 1 minute
Power consumption 100 to 240 V AC Approx. 8 VA max. (11VA max. when EV2 and Serial
communication are added)
24 V AC Approx. 5 VA max. (8 VA max. when EV2 and Serial
communication are added) (*)
24 V DC Approx. 5 W max. (8 W max. when EV2 and Serial
communication are added) (*)
(*) 24 V AC/DC can be specified only for the KT4R model.
