5.2 PC Connection
The Main Unit has a LAN port for PC to program PBX. A default IP address is assigned to each port. A PC
can be connected through LAN connection.
Port Default IP Address Default Subnet Mask
LAN Port 192.168.0.101
255.255.255.0
MNT Port
*1
223.0.0.1
*1
Use USB to LAN adaptor to use the USB port of the PBX as an MNT port.
Connection via LAN
Switching Hub
LAN
PC
LAN Port
Note
For details about connecting a switching hub to the PBX, refer to "4.11.1 LAN Connection for the Main
Unit".
Connection via Virtual Private Network (VPN)
Switching Hub
LAN
PC
Router
Router
VPN
LAN Port
Notice
To access the PBX via VPN, the PC must be in the same VPN.
Document Version 2016-03 Installation Manual 155
5.2 PC Connection
