4.2.2 Names and Locations
KX-NS700
Front Back/Inside
BC
IJ
KL
Q
R TPS
E
F HGDA NO
M
A. STATUS Indicator
B. System Mode Switch
C. LAN Port
D. USB Port
E. EXP-M slot
F. CO Line/Doorphone Free Slot
G. Top Cover
H. Extension Free Slot
I. PBX MODE indicator
J. PFT Port
K. EPG/MOH Ports
L. DPT Port
M. SLT Ports
N. Sub Board
O. Main Board
P. FG Terminal
Q. AC Inlet
R. MPR ID
S. Power Switch
T. FAN
Document Version 2016-03 Installation Manual 75
