2.3 Specifications
2.3.1 General Description
KX-NS700
Main CPU Cortex A8 600 MHz
Power Input 100 V AC to 130 V AC: 2.2 A/200 V AC to 240 V AC: 1.3 A;
50 Hz/60 Hz
Power Consumption (when fully
mounted)
Normal rated power 104 VA
Memory Backup Duration 7 years
Dialing CO Line Dial Pulse (DP) 10 pps, 20 pps
Tone (DTMF) Dialing with Caller ID
(FSK/DTMF)
1600 W Maximum
Extension Dial Pulse (DP) 10 pps, 20 pps
Tone (DTMF) Dialing with Caller ID
(FSK)
Port 1-2 (on pre-installed MCSLC4) support PFT in combination
with the port 1-2 (on an LCOT6) connected to an analog CO
line respectively.
Mode Conversion DP-DTMF, DTMF-DP
Ring Frequency 20 Hz/25 Hz (selectable)
Operating
Environment
Temperature 0 °C to 40 °C (32 °F to 104 °F)
Humidity 10 % to 90 % (non-condensing)
Conference Call Trunk 32 parties (Default) / 96 parties (DSP card installed)
(10 ´
3-party conference call, 12 ´ 8-party conference call, etc.)
Music on Hold (MOH) Internal MOH port: 8 ports (Level Control: 31.5 dB to +31.5 dB
per 0.5 dB)
External MOH port: 2 ports (Available exclusively with EPG
[External Paging])
MOH: Selectable Internal/External Music Source Port
External Paging Maximum 2 Ports (Volume Control: -15.5 dB to per 0.5 dB)
(Available exclusively with MOH)
LAN Port 1 (for LAN connection) 10BASE-T/100BASE-TX
(Auto MDI/MDI-X)
Extension Connection Cable SLT 1-pair wire (T, R)
DPT 1-pair wire (D1, D2)
APT 2-pair wire (T, R, D1, D2)
PT-interface CS 1-pair wire (D1, D2)
PT-interface CS (High-density) 4-pair wire (D1, D2)
DSS Console and Add-on Key
Module
1-pair wire (D1, D2)
36 Installation Manual Document Version 2016-03
2.3.1 General Description
