Panasonic KX-NS Series Installation Manual

4.8 Connection of Extensions
4.8.1 Maximum Cabling Distances of the Extension Wiring
(Twisted Cable)
Cable Maximum Distance
26 AWG:
24 AWG:
22 AWG:
222 m (728 ft)
347 m (1138 ft)
500 m (1640 ft)
347 m (1138 ft)
CAT 5:
Cable Maximum Distance
26 AWG:
24 AWG:
22 AWG:
140 m (459 ft)
229 m (751 ft)
360 m (1181 ft)
229 m (751 ft)
CAT 5:
Cable Maximum Distance
26 AWG:
24 AWG:
22 AWG:
698 m (2289 ft)
1128 m (3700 ft)
1798 m (5897 ft)
1128 m (3700 ft)
CAT 5:
SLT
APT and DSS Console
PT-interface CS
DPT
Cable Maximum Distance
26 AWG:
24 AWG:
22 AWG:
500 m (1640 ft)
720 m (2362 ft)
830 m (2723 ft)
720 m (2362 ft)
CAT 5:
Notice
The maximum cabling distance may vary depending on the conditions.
PT-interface
CS
DPT APT
DSS
Console
SLT
DHLC4 Card
ü ü ü ü ü
MCSLC8, MCSLC16
cards
ü
DLC2, DLC8, DLC16
cards
ü ü ü
"ü" indicates that the extension card supports the terminal.
