KX-NS720
Front Back/Inside
IHJK
C EDBA FG
A. STATUS Indicator
B. EXP-S Port
C. CO Line/Doorphone Free Slot
D. Top Cover
E. Extension Free Slot
F. Sub Board
G. Main Board
H. FG Terminal
I. AC Inlet
J. Power Switch
K. FAN
76 Installation Manual Document Version 2016-03
