– Baud Rate (bps)
– Flow Control
– Command
5. Enter Password.
6. Click Connect button.
Connection via PRI23 Card (KX-NS5290)
PC
ISDN MODEM
ISDN Line
Network
PRI23 Card (KX-NS5290) is installed
in KX-NS700
To connect a PC to the Main Unit
1. Start Off-line WebMC launcher.
2. Click the Connect-Online Mode(C) button.
3. Select the ISDN Remote tab.
4. In Telephone Number, enter a telephone number.
5. In Password, enter the password.
6. Click the Connect button.
MNT Port
By connecting a USB-LAN adaptor to the USB port you can access the PBX over a LAN.
Notice
• When connecting the PC to the MNT port, if the PC is set to obtain the IP address automatically, the
IP address of the PC will be set to an appropriate IP address to establish a connection to the PBX.
• Only recommended USB
-LAN adaptors can be used. For information on recommended products,
consult you dealer.
Document Version 2016-03 Installation Manual 157
5.2 PC Connection
