Manual Programming
Follow the steps below to program the parameters which are not automatically programmed by selecting a
provider.
1. Click the desired tab.
2. Enter information or select settings from the drop-down list for each parameter.
Parameters that Require Manual Programming
Manual programming is compulsory for the following parameters:
• User Name: Specifies the user name (SIP Account) provided by the SIP provider. (Max. 64 characters)
• Authentication ID: Specifies the authentication ID required for registration with the SIP server. (Max. 64
characters)
• Authentication Password: Specifies the authentication password used for registration with the SIP
provider. (Max. 32 characters)
Follow the steps below to program these 3 parameters.
1. Click an Account tab.
2. In the User
Name column, enter the user name provided
by the SIP provider.
3. In the Authentication ID column, enter the
authentication ID required for registration with the SIP
server.
4. In the Authentication Password column, the
authentication password used for registration with the
SIP provider.
5. Click OK.
Adding Settings to Provider Profiles
Follow the steps below to add the settings to provider profiles.
1. Click Add Provider.
A dialog box will appear. Available virtual SIP gateway
port numbers are displayed in the list.
2. Highlight the desired port numbers or click Select All to
select all the virtual SIP gateway port numbers to add
the settings to provider profiles.
3. Click Execute.
Note
For more details about SIP gateway port settings, refer to the PC Programming Manual.
182 Installation Manual Document Version 2016-03
5.6 Programming SIP CO Lines
