Parameter Description
PBX IP Address
Identifies the location of the PBX in the network during VoIP
communications.
VLAN ID
Identifies the ID of the logical segment within the corporate LAN,
through which voice packets from IP telephones travel. For details,
refer to "8.1.3 VLAN (Virtual LAN)".
DiffServ (DS)
Identifies the value for the DS field in the header of IP packets, which
determines
the priority given to packets traveling from IP telephones.
For details, refer to "5.7.4 Setting Diffserv Parameters".
Types of IP Network
The speech quality depends on the type of IP network in use. Managed IP networks provide better speech
quality compared to unmanaged networks such as satellite communications, where quality of service cannot
be guaranteed.
Examples of recommended IP networks
• Digital Leased Line
• IP-VPN (Virtual Private Network)
• Frame Relay
Not recommended
• Satellite
communications (Very Small Aperture
Terminal system [VSAT], etc.)
Note
• Peer-to-peer
calls between IP telephones installed at different locations may not be possible if packet
communication cannot be established between the respective networks. In this case, you need to
configure the network settings (e.g., a VPN router when using an IP-VPN) to establish packet
communication.
• Unlike an IP-VPN, which is set up over a network provider’s own IP network, an Internet VPN is set up
over the Internet. Internet VPNs are not recommended for VoIP communication because transmission
delays and loss of data are likely to occur.
274 Installation Manual Document Version 2016-03
8.1.1 Using a VoIP Network with the PBX
