Panasonic KX-NS Series Installation Manual

KX-NS700 w/
o option
KX-NS700
max.
KX-NS700 w/
1 KX-NS720
KX-NS700 w/
2 KX-NS720
KX-NS700 w/
3 KX-NS720
No. of DPT ports 2
34
(16´2+2)
66
(16´4+2)
98
(16´6+2)
130
(16´8+2)
No. of Digital XDP
ports
2 24
50
(24+26)
76
(24+26´2)
102
(24+26´3)
Total No. of DPTs 4
48
(24+24)
101
(48+27+26)
154
(48+53´2)
207
(48+53´3)
Power Supply Unit Capacity
The pre-installed power supply unit
(PSU) in each PBX supports a different load figure.
PBX Model Maximum Load Figure
KX-NS700
40
KX-NS720
40
Load Figure Calculation
Equipment Type Item Load Figure
PT DPT
1
DSS Console
1
D-XDP
0.5
APT
1.5
IP-PT
0
SIP-EXT
0
CS DPT I/F CS (2ch)
2
DPT I/F CS (8ch)
8
SLT DHLC4
4
SLC8
8
SLC16
16
KX-NS700
(Preinstalled SLC)
4
Calculation Example of KX-NS700
Item Units Load Figure
DPT (KX-DT series) 24
24
D-XDP 24
12
SLT 4
4
IP-PT (KX-NT series) 5
0
48 Installation Manual Document Version 2016-03
