Panasonic KX-NS Series Installation Manual

To remove a slot cover
1. Remove the top cover.
Refer to "Opening the Top Cover" in "4.2.3 Opening/Closing the Top Cover".
2. From the inside, push the tab of the slot cover to the right and push out the left edge of the slot cover.
Ta b
96 Installation Manual Document Version 2016-03
4.2.5 Installing/Removing the Optional Service Cards
