Step 1
Click the desired [Multi-screen] button.
→ Images from the registered cameras will be dis-
played on a selected multi-screen (screen can be
split up to 16 areas). The following are instructions
when displaying on a 4-split screen.
q To display images on a single screen, click the [Live]
button.
w Click a camera title. Live images from the camera
corresponding to the clicked camera title will be dis-
played on the "Live" page of the newly opened win-
dow.
Monitor images from multiple cameras
Images from multiple cameras can be displayed on a multi-screen. Images from 4 cameras (up to 16 cameras) can
be displayed simultaneously. To display images on a multi-screen, it is necessary to register cameras in advance. 4
cameras can be registered as a group and up to 4 groups (16 cameras) can be registered. (☞ Page 65)
Important:
 • Whendisplayingimagesona16-screen,panning,tiltingandzoomingoperationsbecomeunavailablefor
images from the Panasonic PTZ cameras.
 • Whendisplayingimagesona4-screen,panning,tiltingandzoomingoperationsbecomeavailableonlyfor
imagesfromthePanasonicPTZcameras.Refertothe"Readme"fileontheprovidedCD-ROMforfurtherinfor-
mation about the compatible PTZ cameras and their versions.
 • OnlyJPEGimagescanbedisplayedonamulti-screen.Audiowillnotbeheard.
 • WhenthepoweristurnedoffortheLANcableisdisconnectedwhiledisplayingimages,displayingimagesona
multi-screen from the "Live" page will become unavailable.
 • Whendisplayingtheimageonamulti-screenand"16:9"isselectedfor"Aspectratio",theimagewillbedis-
playedalteredverticallytotheaspectratioof"4:3".
q w
