[VIQS(H.264(1))]
Select"On"or"Off"todeterminewhetherornotto
activate the VIQS function for the transmitted (H.264(1))
images.
Default:Off
[VIQS(H.264(2))]
Select"On"or"Off"todeterminewhetherornotto
activate the VIQS function for the transmitted (H.264(2))
images.
Default:Off
Important:
 • WhentheVIQSsettingisactivatedandthesetting
valuefor"Aspectratio"ischangedfrom"4:3"to
"16:9"onthe[JPEG/H.264]tab,makesurethatthe
VIQS setting value does not exceed the maximum
designated range.
Note:
 • Refertothefollowingforsettingprocedureofthe
VIQS area.
Configure the VIQS area
The VIQS area is specified by following the steps below.
Step 1
Drag the mouse on the screen to specify the area.
→ The specified area is displayed with a white frame.
Note:
A selectable area is limited.
Step 2
Select[On]/[Off]toactivate/disactivateadistributed
image of [VIQS (H.264 (1))] or [VIQS (H.264 (2))].
Step 3
Click the [Set] button.
→ This unit is updated wtih the setting contents. To
delete the specified area, click the [Delete] button.
Important:
 • Nosettingcontentsaredeterminedunlessthe[Set]
button is clicked.
• To check the window after VIQS setting, display an
H.264 image on the "Live" page.
