Digiplex EVO • Programming Guide
Version 7.11
Keyswitch Programming | 19
Keyswitch Arming/Disarming Report Codes
For Ademco Slow, Silent Knight Fast, Sescoa, or Ademco Express, key-in desired two-digit hex values from 00 to FF. Use Worksheet 8 on page 20 to record settings.
Ademco Contact ID
• Use section [4033] to program a set of default Ademco report codes, using Table 55 on page 58.
• To program the remaining report codes or change certain defaults, access the individual sections and key-in the desired two-digit hex value, found in Table 59
on page 63.
SIA Format
• Use section [4033] to program a set of SIA report codes, using Table 55 on page 58.
• Codes that have not been set to default can be set as such manually, by entering FF in the appropriate section.
• To disable the reporting of an event, enter 00 in the appropriate section.
Panic Input Option
To use the panic input option when programming keyswitch parameters in sections [0601] to [0632], proceed as follows:
1. Enable partition panic alarm options, by referring to Table 46 on page 52.
2. Enter 5 to access the panic input option (refer to Table 12 on page 19).
3. Enter 0, 1, or 2 to assign the type of panic. As shown in Table 13 on page 19, 0 = police; 1= medical; 2 = fire.
4. Enter 1 to 8 to assign the keyswitch to partitions 1 through 8, respectively (refer to Table 14 on page 19).
* To use this keyswitch definition, one or more PGMs
must be programmed with the Utility Key event (refer
to Event Group 048 in Table 16 on page 21).
** To use this keyswitch definition, refer to Panic Input
Option on page 19.
Table 12: Keyswitch Definitions
Input Value Description
0 Disabled (default)
1Momentary keyswitch
2 Maintained keyswitch
3
Generates a utility key event
on open*
4
Generates a utility key event
on open and close*
5 Panic input option**
* Only applicable for keyswitch definition 5 (panic input option
in Table 12 on page 19). Refer to Panic Input Option on page 19
for details.
Table 13: Keyswitch Partition/Panic Type Assignment
Input Value Description
0
• Not assigned to a partition
(default)
• Panic type 1: police*
1
• Assign keyswitch to partition 1
• Panic type 2: medical*
2
• Assign keyswitch to partition 2
• Panic type 3: fire*
3 Assign keyswitch to partition 3
4 Assign keyswitch to partition 4
5 Assign keyswitch to partition 5
6 Assign keyswitch to partition 6
7 Assign keyswitch to partition 7
8 Assign keyswitch to partition 8
* Only applicable for keyswitch definition 5 (panic input option
in Table 12 on page 19). Refer to Panic Input Option on page 19
for details.
** Select only one of these arming types. If all are OFF,
keyswitch will use regular arming by default.
Table 14: Keyswitch Options/Partition Assignment
Input Value Description
1 Assign keyswitch to partition 1*
2 Assign keyswitch to partition 2*
3
•Disarm only
• Assign keyswitch to partition 3*
4
• OFF: disarm; ON: disarm only if
Stay/Instant armed
• Assign keyswitch to partition 4*
5
•Arm only
• Assign keyswitch to partition 5*
6
•Stay arming**
• Assign keyswitch to partition 6*
7
•Force arming**
• Assign keyswitch to partition 7*
8
• Instant arming**
• Assign keyswitch to partition 8*
