Digiplex EVO • Programming Guide
Version 7.11
Partition Settings | 49
Partition Settings
Use the following section to program the various partitions on your EVO system. Use Worksheet 39 on page 49 to Worksheet 45 on page 56 to record your settings.
Auto-arm Times
Arming/Disarming Report Schedules
NOTE: If a partition is armed outside a schedule, the panel will send an Early to Close [3916] and/or Late to Close [3917] report code (refer to Worksheet 46 on page
56).
[2970]
___/___ Fail to communicate IPR512 3
___/___ Fail to communicate IPR512 3 restore
___/___ Fail to communicate IPR512 4
___/___ Fail to communicate IPR512 4 restore
Worksheet 38: IP Module Report Codes
Section Data Description
[2992]
___/___ Missing IP module
___/___ Missing IP Restore
___/___ IP no service
___/___ IP no service restore
[2993]
___/___ Fail to communicate IPR512 1
___/___ Fail to communicate IPR512 1 restore
___/___ Fail to communicate IPR512 2
___/___ Fail to communicate IPR512 2 restore
[2994]
___/___ Fail to communicate IPR512 3
___/___ Fail to communicate IPR512 3 restore
___/___ Fail to communicate IPR512 4
___/___ Fail to communicate IPR512 4 restore
Worksheet 39: Partition Label Settings for Sections [3100] to [3800]
Section Partition Label Partition #
[3100] ___/___/___/___/___/___/___/___/___/___/___/___/___/___/___/___
1
[3200] ___/___/___/___/___/___/___/___/___/___/___/___/___/___/___/___
2
[3300] ___/___/___/___/___/___/___/___/___/___/___/___/___/___/___/___
3
[3400] ___/___/___/___/___/___/___/___/___/___/___/___/___/___/___/___
4
[3500] ___/___/___/___/___/___/___/___/___/___/___/___/___/___/___/___
5
[3600] ___/___/___/___/___/___/___/___/___/___/___/___/___/___/___/___
6
[3700] ___/___/___/___/___/___/___/___/___/___/___/___/___/___/___/___
7
[3800] ___/___/___/___/___/___/___/___/___/___/___/___/___/___/___/___
8
Worksheet 40: Auto-arm Time Settings
Section Data (Hours 00-23; Minutes (00-59) Partition # Section Data (Hours 00-23; Minutes (00-59) Partition #
[3101] ___/___ : ___/___
1
[3501] ___/___ : ___/___
5
[3201] ___/___ : ___/___
2
[3601] ___/___ : ___/___
6
[3301] ___/___ : ___/___
3
[3701] ___/___ : ___/___
7
[3401] ___/___ : ___/___
4
[3801] ___/___ : ___/___
8
Worksheet 41: Arming Report Schedule Settings
Section Partition # Schedule Interval
Start Time
(From)
End Time
(To)
Days of the Week (Turn ON or OFF)
S M T W T F S H
[3102] 1001
Schedule A ___ ___:___ ___ ___ ___:___ ___ 12345678
Schedule B ___ ___:___ ___ ___ ___:___ ___ 12345678
[3202] 2002
Schedule A ___ ___:___ ___ ___ ___:___ ___ 12345678
Schedule B ___ ___:___ ___ ___ ___:___ ___ 12345678
[3302] 3003
Schedule A ___ ___:___ ___ ___ ___:___ ___ 12345678
Schedule B ___ ___:___ ___ ___ ___:___ ___ 12345678
[3402] 4004
Schedule A ___ ___:___ ___ ___ ___:___ ___ 12345678
Schedule B ___ ___:___ ___ ___ ___:___ ___ 12345678
[3502] 5005
Schedule A ___ ___:___ ___ ___ ___:___ ___ 12345678
Schedule B ___ ___:___ ___ ___ ___:___ ___ 12345678
[3602] 6006
Schedule A ___ ___:___ ___ ___ ___:___ ___ 12345678
Schedule B ___ ___:___ ___ ___ ___:___ ___ 12345678
[3702] 7007
Schedule A ___ ___:___ ___ ___ ___:___ ___ 12345678
Schedule B ___ ___:___ ___ ___ ___:___ ___ 12345678
[3802] 8008
Schedule A ___ ___:___ ___ ___ ___:___ ___ 12345678
Schedule B ___ ___:___ ___ ___ ___:___ ___ 12345678
Worksheet 37: PCS Module Report Codes
Section Data Description

Paradox Digiplex EVO EVO192 V7.11 Specifications

General

Zones	8 on board, expandable to 192
Partitions	8
User Codes	999
PGM Outputs	5 on board, expandable to 250
Remote Firmware Upgrade	Yes
Expandable	Yes
Memory	2048 events
Event Buffer	2048 events
PGMs	5 on board, expandable to 250
Communication	Supports GSM/GPRS/IP reporting
Battery Backup	7 Ah
Number of Zones	8 (expandable to 192)
Operating Temperature	0°C to 50°C (32°F to 122°F)
Humidity	5% to 90% non-condensing
Compatibility	Paradox EVO series
