Digiplex EVO • Programming Guide
Version 7.11
Additional Settings and Modes | 57
Trouble Report Codes
Additional Settings and Modes
The following section provides information on various other settings and modes applicable to your EVO system.
WARNING: The module and label broadcast features will only work when a module is broadcasting its data to a module, or to modules of the same type
and model number.
Worksheet 47: Trouble Report Code Settings
Type Section Data Description Type Section Data Description
Trouble
Report Codes
[3940] ___/___ Future use
Trouble Restore
Report Codes
[3970] ___/___ TLM1 restore
[3941] ___/___ AC failure [3971] ___/___ AC failure restore
[3942] ___/___ Battery failure [3972] ___/___ Battery failure restore
[3943] ___/___ Auxiliary supply [3973] ___/___ Auxiliary supply restore
[3944] ___/___ Bell output (disconnected or overload) [3974] ___/___ Bell output (reconnected or restored)
[3945] ___/___ Clock loss [3975] ___/___ Clock loss restore
[3946] ___/___ Fire loop trouble [3976] ___/___ Fire loop trouble restore
[3947] ___/___ Future use [3977] ___/___ Future use
[3948] ___/___ Future use [3978] ___/___ Future use
[3949] ___/___ Future use [3979] ___/___ Future use
[3950] ___/___ Combus fault [3980] ___/___ Combus fault restore
[3951] ___/___ Module tamper [3981] ___/___ Module tamper restore
[3952] ___/___ ROM check error [3982] ___/___ ROM check error restore
[3953] ___/___ Module TLM [3983] ___/___ Module TLM restore
[3954] ___/___ Module failure to communicate [3984] ___/___ Module failure to communicate restore
[3955] ___/___ Printer fault [3985] ___/___ Printer fault restore
[3956] ___/___ Module AC failure [3986] ___/___ Module AC failure restore
[3957] ___/___ Module battery failure [3987] ___/___ Module battery failure restore
[3958] ___/___ Module auxiliary failure [3988] ___/___ Module auxiliary failure restore
[3959] ___/___ Future use [3989] ___/___ Future use
[3960] ___/___ Wireless transmitter battery low [3990] ___/___ Wireless transmitter battery low restore
[3961] ___/___ Wireless transmitter supervision trouble [3991] ___/___ Wireless transmitter supervision trouble restore
[3962] ___/___ Future use
[3963] ___/___ Future use
[3964] ___/___ Future use
[3965] ___/___ Phone number 1 fail to communicate
[3966] ___/___ Phone number 2 fail to communicate
[3967] ___/___ Phone number 3 fail to communicate
[3968] ___/___ Phone number 4 fail to communicate
[3969] ___/___ Future use
Table 53: Description of Sections [4000] to [4006]
Section
Name Description
[4000]
Display serial number of
control panel and all
modules connected to the
combus
After entering section [4000], the keypad will display the eight-digit serial number of the control panel and firmware
version. For Keypads K641R/K641LX/K641+ and K656: use the  and  keys to scroll through the serial number of each
module connected to the combus. The firmware version of some modules will also be displayed.
[4001] Module reset Reset a module’s programmed contents to its default settings, by entering its serial number.
[4002] Locate/unlocate module
Locate a specific module (e.g., detector, zone expander, etc.) connected to the combus, by entering the module's serial
number. The green Locate LED on the module will flash until the serial number is re-entered, or the appropriate Ta mp er
or Unlocate switch is pressed on the module.
[4003] Module programming mode Enter the serial number of the module you wish to program.
[4004]
Module broadcast
Copy the contents of all programming sections from one module, to one or more modules of the same type.
Enter the serial number of the source module, followed by the serial numbers of the modules you wish to program. To
begin transferring data, press
ACC on the K641R/K641LX/K641+ keypads, or on the K656 keypad.
Label broadcast
Copy user, door, and partition labels from the control panel, to all keypads and printer modules connected to the
combus. To transmit the labels, enter 0 0 in section [4004]. From the Destination screen, press
ACC on the K641R/
K641LX/K641+ keypads, or on the K656 keypad.
[4005] Quick module scanning
After entering the section, the control panel will scan all addresses assigned to the modules. If any missing modules are
detected (i.e., detector removed from the combus), the control panel will erase the module's serial number, thus
removing the module from the control panel's memory.
[4006] Module scanning
After entering the section, the control panel will scan all addresses on the combus. If any missing modules are detected
(i.e., detector removed from the combus), the control panel will erase the module's serial number, thus removing the
module from the control panel's memory. If new modules are detected, the serial number will be entered in the control
panel’s memory.
