Paradox Digiplex EVO EVO192 V7.11 User Manual

Version 7.11
56 | Special and Trouble Report Codes
Digiplex EVO • Programming Guide
No Movement Schedule
WARNING: The Start and End Time of a schedule cannot cross over into another day. For example, to program a shift from 10 PM to 6 AM the next morning,
you must program the schedule as follows: Schedule A – start time: 22:00 and end time: 23:59; then program Schedule B – start time: 00:00 and
end time: 06:00. The schedule will not be interrupted between 23:59 and 00:00.
Special and Trouble Report Codes
Use the following section to program the special and trouble report codes on your EVO system. Use Worksheet 46 on page 56, as well as Worksheet 47 on page 57 to
record your settings.
For Ademco Slow, Silent Knight Fast, Sescoa, or Ademco Express, key-in desired two-digit hex value from 00 to FF.
Ademco Format
• Use section [4034] (Special System Report Codes), [4035] (Special Arming/Disarming Report Codes), [4036] (Special Alarm Report Codes), and [4037] (Trouble/
Trouble Restore Report Codes) to program a set of default Ademco report codes, using Table 55 on page 58.
• To program the remaining report codes or change certain defaults, access the individual sections and key-in the desired two-digit hex value, found in Table 59
on page 63.
SIA Format
• Use section [4034] (Special System Report Codes), [4035] (Special Arming/Disarming Report Codes), [4036] (Special Alarm Report Codes), and [4037] (Trouble/
Trouble Restore Report Codes) to program a set of SIA report codes, using Table 55 on page 58.
• Codes that have not been set to default can be set as such manually, by entering FF in the appropriate section.
• To disable the reporting of an event, enter 00 in the appropriate section.
Special Report Codes
Worksheet 45: No Movement Schedule Settings
Section Partition # Interval
Start Time
(From)
End Time
(To)
Days of the Week (Turn ON or OFF)
S M T W T F S H
[3131] 1
Schedule A ___ ___:___ ___ ___ ___:___ ___ 12345678
Schedule B ___ ___:___ ___ ___ ___:___ ___ 12345678
[3231] 2
Schedule A ___ ___:___ ___ ___ ___:___ ___ 12345678
Schedule B ___ ___:___ ___ ___ ___:___ ___ 12345678
[3331] 3
Schedule A ___ ___:___ ___ ___ ___:___ ___ 12345678
Schedule B ___ ___:___ ___ ___ ___:___ ___ 12345678
[3431] 4
Schedule A ___ ___:___ ___ ___ ___:___ ___ 12345678
Schedule B ___ ___:___ ___ ___ ___:___ ___ 12345678
[3531] 5
Schedule A ___ ___:___ ___ ___ ___:___ ___ 12345678
Schedule B ___ ___:___ ___ ___ ___:___ ___ 12345678
[3631] 6
Schedule A ___ ___:___ ___ ___ ___:___ ___ 12345678
Schedule B ___ ___:___ ___ ___ ___:___ ___ 12345678
[3731] 7
Schedule A ___ ___:___ ___ ___ ___:___ ___ 12345678
Schedule B ___ ___:___ ___ ___ ___:___ ___ 12345678
[3831] 8
Schedule A ___ ___:___ ___ ___ ___:___ ___ 12345678
Schedule B ___ ___:___ ___ ___ ___:___ ___ 12345678
Worksheet 46: Special Report Code Settings
Type Section Data Description Type Section Data Description
Special System
Report Codes
[3900] ___/___ Power up after total power down
Special Disarming
Report Codes
[3920] ___/___ Cancel auto-arm
[3901] ___/___ Software reset (watchdog) [3921] ___/___ Quick disarm
[3902] ___/___ Test report [3922] ___/___ PC disarming
[3903] ___/___ Listen-in to follow (request to start session) [3923] ___/___ PC disarming after alarm
[3904] ___/___ BabyWare login request (callback only) [3924] ___/___ Cancel alarm
[3905] ___/___ BabyWare log off [3925] ___/___ Future use
[3906] ___/___ Installer in [3926] ___/___ Early to open (refer to Worksheet 42 on page 50)
[3907] ___/___ Installer out [3927] ___/___ Late to open (refer to Worksheet 42 on page 50)
[3908] ___/___ Future use [3928] ___/___ Remote disarming (ADM2, LSN4)
[3909] ___/___ Future use [3929] ___/___ Future use
Special Arming
Report Codes
[3910] ___/___ Auto-arming
Special Alarm
Report Codes
[3930] ___/___ Emergency panic
[3911] ___/___ PC arming [3931] ___/___ Auxiliary panic
[3912] ___/___ Late to close (Auto-arming) [3932] ___/___ Fire panic
[3913] ___/___ No movement [3933] ___/___ Recent closing
[3914] ___/___ Partial arming [3934] ___/___ Police code
[3915] ___/___ Quick arming [3935] ___/___ Zone shutdown
[3916] ___/___ Early to close (refer to Worksheet 41 on page 49) [3936] ___/___ Duress
[3917] ___/___ Late to close (refer to Worksheet 41 on page 49) [3937] ___/___ Keypad lockout
[3918] ___/___ Remote arming (ADM2, LSN4) [3938] ___/___ Voice lockout
[3919] ___/___ Close delinquency [3939] ___/___ Future use

Paradox Digiplex EVO EVO192 V7.11 Specifications

General

Zones	8 on board, expandable to 192
Partitions	8
User Codes	999
PGM Outputs	5 on board, expandable to 250
Remote Firmware Upgrade	Yes
Expandable	Yes
Memory	2048 events
Event Buffer	2048 events
PGMs	5 on board, expandable to 250
Communication	Supports GSM/GPRS/IP reporting
Battery Backup	7 Ah
Number of Zones	8 (expandable to 192)
Operating Temperature	0°C to 50°C (32°F to 122°F)
Humidity	5% to 90% non-condensing
Compatibility	Paradox EVO series
