36 | Access Control Sections
Digiplex EVO • Programming Guide
Access Levels
Each access level is a combination of access control doors. For example, if option 1 in the first screen is enabled in section [2601], Level 01 will allow access only to
Door 01. Use Worksheet 16 on page 36 to record your settings.
Holidays
When H is enabled in a schedule, access is permitted to users during the days programmed in the sections below. Use Worksheet 17 on page 36 to record your
settings.
Worksheet 16: Programming Access Levels
Access to Doors (Turn ON or OFF access)
Section Level
First Screen
(Doors 01 to 08)
Second Screen
(Doors 09 to 16)
Third Screen
(Doors 17 to 24)
Fourth Screen
(Doors 25 to 32)
[2601] 01 12345678 12345678 12345678 12345678
[2602] 02 12345678 12345678 12345678 12345678
[2603] 03 12345678 12345678 12345678 12345678
[2604] 04 12345678 12345678 12345678 12345678
[2605] 05 12345678 12345678 12345678 12345678
[2606] 06 12345678 12345678 12345678 12345678
[2607] 07 12345678 12345678 12345678 12345678
[2608] 08 12345678 12345678 12345678 12345678
[2609] 09 12345678 12345678 12345678 12345678
[2610] 10 12345678 12345678 12345678 12345678
[2611] 11 12345678 12345678 12345678 12345678
[2612] 12 12345678 12345678 12345678 12345678
[2613] 13 12345678 12345678 12345678 12345678
[2614] 14 12345678 12345678 12345678 12345678
[2615] 15 12345678 12345678 12345678 12345678
Worksheet 17: Programming Holidays
Days
Section Month
First Screen
(Days 01 to 08)
Second Screen
(Days 09 to 16)
Third Screen
(Days 17 to 24)
Fourth Screen
(Days 25 to 31)
[2701] January 12345678 12345678 12345678 1234567*
[2702] February 12345678 12345678 12345678 1234567*
[2703] March 12345678 12345678 12345678 1234567*
[2704] April 12345678 12345678 12345678 1234567*
[2705] May 12345678 12345678 12345678 1234567*
[2706] June 12345678 12345678 12345678 1234567*
[2707] July 12345678 12345678 12345678 1234567*
[2708] August 12345678 12345678 12345678 1234567*
[2709] September 12345678 12345678 12345678 1234567*
[2710] October 12345678 12345678 12345678 1234567*
[2711] November 12345678 12345678 12345678 1234567*
[2712] December 12345678 12345678 12345678 1234567*

Paradox Digiplex EVO EVO192 V7.11 Specifications

General

Zones	8 on board, expandable to 192
Partitions	8
User Codes	999
PGM Outputs	5 on board, expandable to 250
Remote Firmware Upgrade	Yes
Expandable	Yes
Memory	2048 events
Event Buffer	2048 events
PGMs	5 on board, expandable to 250
Communication	Supports GSM/GPRS/IP reporting
Battery Backup	7 Ah
Number of Zones	8 (expandable to 192)
Operating Temperature	0°C to 50°C (32°F to 122°F)
Humidity	5% to 90% non-condensing
Compatibility	Paradox EVO series
