Digiplex EVO • Programming Guide
Version 7.11
Keypad Programming | 67
TM50 and TM70
The keypad’s serial number can be found on the keypad’s backplate. It can also be viewed by pressing Menu >Advanced > Product Info.
Figure 6: The TM50 and TM70 Keypads
Table 63: Description of Sections [001] to [003] for the TM50 and TM70 Keypads
Section Option Description OFF ON Section Option Description OFF ON
Section [001]
Keypad Partition Assignment
1Partition 1

Disabled  Enabled
Section [002]
Keypad Options
1
Display user code on enter code
screen
 Disabled

Enabled
2Partition 2

Disabled  Enabled 2 Display exit delay

Disabled  Enabled
3Partition 3

Disabled  Enabled 3 Display entry delay  Disabled  Enabled
4Partition 4

Disabled  Enabled 4 Use confidential mode  Disabled

Enabled
5Partition 5

Disabled  Enabled 5
No code needed to exit
confidential mode
 Disabled

Enabled
6Partition 6

Disabled  Enabled 6 Beep on exit delay

Disabled  Enabled
7Partition 7

Disabled  Enabled 7
Off = Temperature input
(automatically broadcasts
On = Zone input

Disabled  Enabled
8Partition 8

Disabled  Enabled 8 Keypad Tamper

Disabled  Enabled
Section [003]
Trouble Warning Beep and Time/Date Display
1 System clock trouble  Disabled

Enabled
2 Communication trouble

Disabled  Enabled
3 Module trouble  Disabled

Enabled
4 Zone trouble  Disabled

Enabled
5 Future use  -

-
6 Future use  -

-
7 Future use  -

-
8 Future use  -

-
Worksheet 52: TM50/TM70 Keypad Settings for Sections [004] to [005]
Section Data Description Default Setting
[004] ___/___/___ (005-255 sec.) Confidential mode timer (TM50/TM70 only) 120
[005] ___/___/___/___/___/___ 6-digit serial number (of broadcasting TM50/TM70)
Display out temperature from another keypad*
-
[401] ___/___
00 = Follow panel option
01 = EOL Off
02 = EOL On EOL Option 00
* If option [7] in section [002] is enabled, display the outdoor temperature from the keypad serial number entered in [005]. Will automatically display the serial number of the first
keypad set to broadcast, or enter a serial number manually.
TM50
TM70

Paradox Digiplex EVO EVO192 V7.11 Specifications

General

Zones	8 on board, expandable to 192
Partitions	8
User Codes	999
PGM Outputs	5 on board, expandable to 250
Remote Firmware Upgrade	Yes
Expandable	Yes
Memory	2048 events
Event Buffer	2048 events
PGMs	5 on board, expandable to 250
Communication	Supports GSM/GPRS/IP reporting
Battery Backup	7 Ah
Number of Zones	8 (expandable to 192)
Operating Temperature	0°C to 50°C (32°F to 122°F)
Humidity	5% to 90% non-condensing
Compatibility	Paradox EVO series
