Version 7.11
66 | Keypad Programming
Digiplex EVO • Programming Guide
WARNING: All event groups, except groups 064 to 067, can be used to program the module’s PGM. With the K641LX, all event groups can be used to
program the module’s PGM except group 067. Refer to Programmable Outputs on page 21, for details.
Worksheet 48: Keypad Settings for Sections [007] to [013]
Section Data Description Default Setting
[007] ___/___/___ (005-255 sec.) Confidential mode timer 120
[008] ___/___/___ (000-255; refer to option 3 in section [006]) PGM timer 005
[008] ___/___/___ (000-255 sec.) Door unlocked period* 005
[009] ___/___/___ (005-255 sec. added to section [008]) Door unlocked period extension* 015
[010] ___/___/___ (000-255 sec.) Door left open interval* 060
[011] ___/___/___ (000-255 sec.) Door left open pre-alarm timer* 015
[012] ___/___/___ (000-255 sec.) Beep timer for door left open alarm* 005
[013] ___/___/___ (000-255 sec.) Beep timer for door forced open alarm* 005
* Section/option is only available on K641R.
Worksheet 49: Door Unlocked Schedule (K641R only)
Section Interval
Start Time
(From)
End Time
(To)
Days of the Week (Turn ON or OFF)
S M T W T F S H
[017]
Schedule A ___ ___:___ ___ ___ ___:___ ___ 12345678
Schedule B ___ ___:___ ___ ___ ___:___ ___ 12345678
Table 61: Beeping Assignment Options
Section Option Description OFF ON
Section [018]
Beeping Assignment
1Partition 1
Mute Audible
2Partition 2
Mute Audible
3Partition 3
Mute Audible
4Partition 4
Mute Audible
5Partition 5
Mute Audible
6Partition 6
Mute Audible
7Partition 7
Mute Audible
8Partition 8
Mute Audible
= Default
Worksheet 50: PGM Activation and Deactivation
Description
Event Group Feature Group Start # End #
Section Data Section Data Section Data Section Data
PGM activation [009] __/__/__ [010] __/__/__ [011] __/__/__ [012] __/__/__
PGM deactivation
[013] __/__/__ [014] __/__/__ [015] __/__/__ [016] __/__/__
Table 62: Testing Keypad’s PGM Output
Section Description
[020] The keypad’s PGM output will be activated for 8 seconds
Worksheet 51: Keypad options 2
[401] ___/___
00 = Follow panel option
01 = EOL Off
02 = EOL On EOL Option 00
