40 | Control Panel Settings
Digiplex EVO • Programming Guide
Control Panel Settings
Use the following section to record control panel settings for your EVO system. Use Worksheet 20 on page 40 to record your settings.
System Options
Use the following section to program system options on your EVO system. Table 27 on page 40 provides information on sections [3029] through [3035].
Table 26: Daylight Saving Time (DST) Schedule for EVO192
Input Value
Schedule Used
Input Value
Schedule Used
000 Mexico; St.-Johns; Bahamas; Turks and Caicos 010 New-Zealand; Chatham
001 Cuba 011 Tonga
002 Brazil 012 Iraq; Syria
003Chile 013Israel (TBC)
004 Falkland Islands 014 Lebanon; Kyrgyzstan
005 Paraguay 015 Palestine
006 European Union; United Kingdom; Greenland 016 Egypt
007 Russia and surrounding countries 017 Namibia
008
South Australia; Victoria; Australian Capital Territory; New
South Wales
018 Canada; United States (default)
009 Tasmania; Lord Howe Island 019 New Zealand
Worksheet 20: Control Panel Settings
Section Data Description
Default
Setting
[3001] __/__/__ Installer lock 000
[3010] __/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/__/ PC phone number (32 digits) -
[3011] __/__/__/__ Panel identification 0000
[3012] __/__/__/__ PC password 0000
[3020] __/__ Panel partition (00-08) 00
[3021] __/__ Trouble shutdown (00-15) 00
[3022] __/__/__
DST schedule
(refer to Table 26 on page 40) 018
Table 27: Description of Sections [3029] to [3035]
Section Option Description OFF ON Section Option Description OFF ON
Section [3029]
System Options 1
1
Enable if using an RTX3 without
an K641/ K641+ / K641R*
 Disabled

Enabled
Section [3030]
System Options 2
1
PGM 1 = Two-wire smoke detector
input (255)
 Disabled

Enabled
2 Future use
--
2 No bell cut-off during pulse alarm  Disabled

Enabled
3 Future use
--
3
Daylight Saving Time
(refer to Table 26 on page 40)

Disabled  Enabled
4 EN 50131 compliant mode  Disabled

Enabled 4 Shabbat feature  Disabled

Enabled
5 Anti-mask supervision
Table 30 on
page 42
Table 30 on
page 42
5 Battery charge current  350 mA

850 mA
6 Anti-mask supervision
Table 30 on
page 42
Table 30 on
page 42
6 AC failure not displayed as trouble  Disabled

Enabled
7
Generate anti-mask trouble if
detected on bypass zone
 Yes

No 7 Clear bell limit trouble  On restore

Manually
8
Restrict arming on anti-mask
trouble
 Disabled

Enabled 8 Combus speed*  Normal

High
Section [3031]
Partition Options 1
1Partition 1

Disabled  Enabled
Section [3032]
Partition Options 2
1 Bell/siren output in partition 1

Disabled  Enabled
2Partition 2  Disabled

Enabled 2 Bell/siren output in partition 2  Disabled

Enabled
3Partition 3  Disabled

Enabled 3 Bell/siren output in partition 3  Disabled

Enabled
4Partition 4  Disabled

Enabled 4 Bell/siren output in partition 4  Disabled

Enabled
5Partition 5  Disabled

Enabled 5 Bell/siren output in partition 5  Disabled

Enabled
6Partition 6  Disabled

Enabled 6 Bell/siren output in partition 6  Disabled

Enabled
7Partition 7  Disabled

Enabled 7 Bell/siren output in partition 7  Disabled

Enabled
8Partition 8  Disabled

Enabled 8 Bell/siren output in partition 8  Disabled

Enabled
* Not supported on RTX3 V6.0 or higher.

Paradox Digiplex EVO EVO192 V7.11 Specifications

General

Zones	8 on board, expandable to 192
Partitions	8
User Codes	999
PGM Outputs	5 on board, expandable to 250
Remote Firmware Upgrade	Yes
Expandable	Yes
Memory	2048 events
Event Buffer	2048 events
PGMs	5 on board, expandable to 250
Communication	Supports GSM/GPRS/IP reporting
Battery Backup	7 Ah
Number of Zones	8 (expandable to 192)
Operating Temperature	0°C to 50°C (32°F to 122°F)
Humidity	5% to 90% non-condensing
Compatibility	Paradox EVO series
