46 | PCS GSM/GPRS Communicator Module
Digiplex EVO • Programming Guide
PCS GSM/GPRS Communicator Module
Use the following section to program the PCS GSM/GPRS Communicator Module on your EVO system. Use Worksheet 29 on page 46 to Worksheet 38 on page 49 to
record your settings.
BabyWare/PCS Module Connection
PCS Module Programming
PCS Module Programming
Table 39: Description of Sections [3133] to [3833]
Option Description
Partition 1
[3133]
Partition 2
[3233]
Partition 3
[3333]
Partition 4
[3433]
Partition 5
[3533]
Partition 6
[3633]
Partition 7
[3733]
Partition 8
[3833]
OFF ON OFF ON OFF ON OFF ON OFF ON OFF ON OFF ON OFF ON
1 Telephone number 1
















2 Telephone number 2 















3 Telephone number 3 















4 Telephone number 4 















5 Telephone number 5 















6 Telephone number 6 















7 Telephone number 7 















8 Telephone number 8 















= Default
Worksheet 29: BabyWare/PCS Module Connection Settings
Section Data Description
[2960] ___/___/___/___/___/___/___/___/___/___/___/___/___/___/___/___/ Access point name (APN) part 1 (e.g., internet.com)
[2961] ___/___/___/___/___/___/___/___/___/___/___/___/___/___/___/___/ Access point name (APN) part 2 (e.g., wap.provider.com)
[2962] ___/___/___/___/___/___/___/___/___/___/___/___/___/___/___/___/ User name part 1
[2963] ___/___/___/___/___/___/___/___/___/___/___/___/___/___/___/___/ User name part 2
[2964] ___/___/___/___/___/___/___/___/___/___/___/___/___/___/___/___/ Password part 1
[2965] ___/___/___/___/___/___/___/___/___/___/___/___/___/___/___/___/ Password part 2
[2966] ___/___/___/___/___ Port (default = 10000)
[3013] ___/___/___/___/___/___/___/___/___/___/___/___/___/___/___/___/ Installer software password (BabyWare) (default = admin)
Table 40: Section [2950] GSM Options
Option
Description
(GSM Reporting)
Option Description
1 2 Primary Backup
3
Future use
OFF OFF Landline Landline 4
Future use
OFF ON Landline GSM
ON OFF GSM Landline
ON ON GSM GSM
5 6
Description
(GSM/GPRS No Service Supervision)
7
GSM/GPRS module tamper (need PCS250 version 1.2
and higher)
OFF OFF Disabled
OFF ON
ON OFF When disarmed: trouble only; when armed: trouble only
OFF ON When disarmed: trouble only; when armed: audible only 8
GSM/GPRS RF jamming supervision
ON ON Silent alarm becomes audible alarm OFF ON
Worksheet 30: PCS Module Settings
Section Data Description
[2951] ___/___ Default: 00 Panel supervision lost (reporting code)
[2952] ___/___/___ (000 to 255) x 2 seconds GSM no service timer (default: 016)

Paradox Digiplex EVO EVO192 V7.11 Specifications

General

Zones	8 on board, expandable to 192
Partitions	8
User Codes	999
PGM Outputs	5 on board, expandable to 250
Remote Firmware Upgrade	Yes
Expandable	Yes
Memory	2048 events
Event Buffer	2048 events
PGMs	5 on board, expandable to 250
Communication	Supports GSM/GPRS/IP reporting
Battery Backup	7 Ah
Number of Zones	8 (expandable to 192)
Operating Temperature	0°C to 50°C (32°F to 122°F)
Humidity	5% to 90% non-condensing
Compatibility	Paradox EVO series
