Digiplex EVO • Programming Guide
Version 7.11
Programmable Outputs | 21
Programmable Outputs
PGM Programming
1. Enter section [0901] - [0932].
2. Enter the eight-digit module or panel serial number and three-digit output number.
3. Enter the three-digit Event Group, Feature Group, Start #, and End # for PGM activation.
4. Enter the three-digit Event Group, Feature Group, Start # and End # for PGM deactivation.
5. Define the PGM Delay value (001 to 255 x 1 sec./min.). Default is set to 15 minutes.
6. Set your PGM options. Refer to table 15.
Event and Feature Groups
Notes for Table 16
Table 15: PGM Options
Option Description
PGM #
OFF ON
1 PGM deactivation after (OFF = deactivation event; ON = PGM timer)
2 PGM base time (OFF = seconds; ON = minutes)
3
Flexible PGM deactivation option (OFF = PGM timer only; ON = PGM timer and/
or deactivation event)
4 PGM initial state (OFF = normally open; ON = normally closed)
5 PGM Time base ( OFF = follow options 2, ON = hour)
6 to 8 Future use - -
000 = Occurs in all partitions enabled in the system (refer to section
[3031], in Table 27 on page 40)
001 = Partition 1 002 = Partition 2 003 = Partition 3 004 = Partition 4
255 = Occurs in at least one partition enabled in the system 005 = Partition 5 006 = Partition 6 007 = Partition 7 008 = Partition 8
Table 16: List of Event and Feature Groups
A
Event Group
Event
B
Feature Group
Feature
C
Start #
D
End #
000 Zone is OK
000
255 = any zone #
Zone numbers
001 to 192 001 to 192
001 Zone is open 001 to 192 001 to 192
002 Zone is tampered 001 to 192 001 to 192
003 Zone is in fire loop trouble 001 to 192 001 to 192
004 Non-reportable event 000 TLM trouble 000 000
To Next Page
