70 | Keypad Programming
Digiplex EVO • Programming Guide
Wireless 2WPGM Activation/Deactivation Events
Use Worksheet 55 on page 70 to record your settings for the 2WPGM activation/deactivation events.
2WPGM Delays
Use Worksheet 56 on page 70 to record your settings for the 2WPGM delays.
2WPGM Options
Worksheet 55: 2WPGM Activation/Deactivation Events
Section 2WPGM Event Group Section Feature Group Section Start # Section End #
2WPGM
Activation
[910] 2WPGM 1 ___/___/___ [911] ___/___/___ [912] ___/___/___ [913] ___/___/___
[920] 2WPGM 2 ___/___/___ [921] ___/___/___ [922] ___/___/___ [923] ___/___/___
[930] 2WPGM 3 ___/___/___ [931] ___/___/___ [932] ___/___/___ [933] ___/___/___
[940] 2WPGM 4 ___/___/___ [941] ___/___/___ [942] ___/___/___ [943] ___/___/___
[950] 2WPGM 5 ___/___/___ [951] ___/___/___ [952] ___/___/___ [953] ___/___/___
[960] 2WPGM 6 ___/___/___ [961] ___/___/___ [962] ___/___/___ [963] ___/___/___
[970] 2WPGM 7 ___/___/___ [971] ___/___/___ [972] ___/___/___ [973] ___/___/___
[980] 2WPGM 8 ___/___/___ [981] ___/___/___ [982] ___/___/___ [983] ___/___/___
2WPGM
Deactivation
[914] 2WPGM 1 ___/___/___ [915] ___/___/___ [916] ___/___/___ [917] ___/___/___
[924] 2WPGM 2 ___/___/___ [925] ___/___/___ [926] ___/___/___ [927] ___/___/___
[934] 2WPGM 3 ___/___/___ [935] ___/___/___ [936] ___/___/___ [937] ___/___/___
[944] 2WPGM 4 ___/___/___ [945] ___/___/___ [946] ___/___/___ [947] ___/___/___
[954] 2WPGM 5 ___/___/___ [955] ___/___/___ [956] ___/___/___ [957] ___/___/___
[964] 2WPGM 6 ___/___/___ [965] ___/___/___ [966] ___/___/___ [967] ___/___/___
[974] 2WPGM 7 ___/___/___ [975] ___/___/___ [976] ___/___/___ [977] ___/___/___
[984] 2WPGM 8 ___/___/___ [985] ___/___/___ [986] ___/___/___ [987] ___/___/___
Worksheet 56: 2WPGM Delays
Section 2WPGM Delay Value Range Description Default Setting
[918] ___/___/___ (001 to 255 x 1 sec./min.) 2WPGM 1 delay 5 sec./min.
[928]
___/___/___ (001 to 255 x 1 sec./min.) 2WPGM 2 delay 5 sec./min.
[938]
___/___/___ (001 to 255 x 1 sec./min.) 2WPGM 3 delay 5 sec./min.
[948]
___/___/___ (001 to 255 x 1 sec./min.) 2WPGM 4 delay 5 sec./min.
[958]
___/___/___ (001 to 255 x 1 sec./min.) 2WPGM 5 delay 5 sec./min.
[968]
___/___/___ (001 to 255 x 1 sec./min.) 2WPGM 6 delay 5 sec./min.
[978]
___/___/___ (001 to 255 x 1 sec./min.) 2WPGM 7 delay 5 sec./min.
[988]
___/___/___ (001 to 255 x 1 sec./min.) 2WPGM 8 delay 5 sec./min.
Table 69: 2WPGM Options
Option
Description
PGM 1
[919]
PGM 2
[929]
PGM 3
[939]
PGM 4
[949]
PGM 5
[959]
PGM 6
[969]
PGM 7
[979]
PGM 8
[989]
OFF ON OFF ON OFF ON OFF ON OFF OFF ON ON ON ON ON ON
1
PGM deactivation event after: see options
















2
PGM base time (On = min. / Off = sec.)
















3 Future use

4 Future use

5 Future use

6 Future use

7 Future use

8 Flexible PGM deactivation: see options table 















= Default
Table 70: 2WPGM; Options 1 and 8
Option
Description
1 8
OFF OFF Deactivation event
OFF ON Deactivation event
ON OFF PGM timer
ON ON PGM timer or deactivation event
Table 71: 2WPGM Tamper Trouble
Section Description
[991] The serial number of the 2WPGM that is in tamper trouble will be displayed.
Table 72: 2WPGM Supervision Trouble
Section Description
[992] The serial number of the 2WPGM that is in supervision trouble will be displayed.
