Hardware Connections for the Control Panel
The following section provides information on certain hardware connections for your EVO192 control panel. For detailed information, including connection
diagrams, refer to the Digiplex EVO192 Installation Guide available from paradox.com.
Milliamp Consumption
Using Worksheet 57 on page 73, proceed as follows:
1. Calculate the total number of milliamps (mA) required by each device, module, and accessory in your EVO system. Make sure to take into account devices con-
nected to the control panel’s PGM outputs. Since the bell output has its own power supply, do not include the sirens which are connected to it in your
calculation.
2. If the grand total is less than 700 mA, proceed to step 3. If the value is greater, an external power supply will be required to provide the additional power
needed.
3. Due to the degradation of a power signal over long distances (if such is the case, the PS17 Paradox Power Supply Module is recommended), each length (or
run) of wire in the system can support only a specific number of milliamps (mA). Using Table 76 on page 74, determine how many milliamps each run of wire
can support.
Worksheet 57: Milliamp Consumption of Various Devices
Device QTY
Consumption for
Each
Total
(mA)
LCD keypad(s) (K656, K641LX, K641+) __________ x 110 mA __________
LCD keypad(s) with built-in reader (K641R) __________ x 120 mA __________
Motion detector module(s) (DG85, DM50/60/70) __________ x 30 mA __________
Door contact module(s) (ZC1) __________ x 15 mA __________
1-Zone expansion module(s) (ZX1) __________ x 30 mA __________
4-Zone expansion module(s) (ZX4) __________ x 30 mA __________
8-Zone expansion module(s) (ZX8) __________ x 30 mA __________
8-Zone expansion modules (ZX82) __________ x 100 mA __________
Magellan wireless expansion module(s) (RTX3) __________ x 35 mA __________
4-PGM expansion module(s) (PGM4) __________ x 150 mA __________
8-PGM expansion module(s) (PGM82) x 315 mA __________
Printer module(s) (PRT3/BUS2SER) __________ x 25 mA __________
Hub and bus isolator(s) (HUB2) __________ x 50 mA __________
Access control module(s) (ACM12)
(The ACM12 consumes 130mA from its own power supply and cannot be
powered by the combus) __________ x 120 mA __________
Internet module __________ x 110 mA __________
Plug-in voice module (VDMP3) __________ x 35 mA __________
PCS module __________ x 600 mA __________
Other devices such as hardwired motion detectors __________ __________
Grand Total
(The maximum available milliamps is 700 mA) __________
