Version 7.11
30 | Programmable Outputs
Digiplex EVO • Programming Guide
Utility Keys
NOTE: Refer to the RTX3 Reference and Installation Manual for instructions on how to program remote control buttons.
Input Speeds
Installer Code Programming
Table 17: Description of Utility Keys
Utility Key Event Keypad Utility Keys
Keyswitch Inputs
(definition = [3])
Keyswitch Inputs
(definition = [4])
Remote Control
1 1 & 2 Keyswitch input 1 opens Keyswitch input 1 opens Utility key 1 remote control button
2 4 & 5 Keyswitch input 2 opens Keyswitch input 1 closes Utility key 2 remote control button
3 7 & 8 Keyswitch input 3 opens Keyswitch input 2 opens Utility key 3 remote control button
4
CLEAR & 0 or * & 0
Keyswitch input 4 opens Keyswitch input 2 closes Utility key 4 remote control button
5 2 & 3 Keyswitch input 5 opens Keyswitch input 3 opens Utility key 5 remote control button
6 5 & 6 Keyswitch input 6 opens Keyswitch input 3 closes -
7 8 & 9 Keyswitch input 7 opens Keyswitch input 4 opens -
8
0 &
ENTER or 0 & #
Keyswitch input 8 opens Keyswitch input 4 closes -
9 - Keyswitch input 9 opens Keyswitch input 5 opens -
10 - Keyswitch input 10 opens Keyswitch input 5 closes -
11 - Keyswitch input 11 opens Keyswitch input 6 opens -
12 - Keyswitch input 12 opens Keyswitch input 6 closes -
13 - Keyswitch input 13 opens Keyswitch input 7 opens -
14 - Keyswitch input 14 opens Keyswitch input 7 closes -
15 - Keyswitch input 15 opens Keyswitch input 8 opens -
16 - Keyswitch input 16 opens Keyswitch input 8 closes -
17 - Keyswitch input 17 opens Keyswitch input 9 opens -
18 - Keyswitch input 18 opens Keyswitch input 9 closes -
-
-
31 - Keyswitch input 31 opens Keyswitch input 16 opens -
32 - Keyswitch input 32 opens Keyswitch input 16 closes -
33 - - Keyswitch input 17 opens -
34 - - Keyswitch input 17 closes -
--
-
63 - - Keyswitch input 32 opens -
64 - - Keyswitch input 32 closes -
Worksheet 9: Input Speeds
Section
Data: Decimal Value (001 to
255 x 30 msec.)
Description
(Default Setting: 600 msec.)
Section
Data: Decimal Value (001 to
255 x 30 msec.)
Description
(Default Setting: 600 msec.)
[0961] ___/___/___ Input speed of input 01 [0969] ___/___/___ Input speed of input 09 (ATZ of input 01)
[0962] ___/___/___ Input speed of input 02 [0970] ___/___/___ Input speed of input 10 (ATZ of input 02)
[0963] ___/___/___ Input speed of input 03 [0971] ___/___/___ Input speed of input 11 (ATZ of input 03)
[0964] ___/___/___ Input speed of input 04 [0972] ___/___/___ Input speed of input 12 (ATZ of input 04)
[0965] ___/___/___ Input speed of input 05 [0973] ___/___/___ Input speed of input 13 (ATZ of input 05)
[0966] ___/___/___ Input speed of input 06 [0974] ___/___/___ Input speed of input 14 (ATZ of input 06)
[0967] ___/___/___ Input speed of input 07 [0975] ___/___/___ Input speed of input 15 (ATZ of input 07)
[0968] ___/___/___ Input speed of input 08 [0976] ___/___/___ Input speed of input 16 (ATZ of input 08)
Worksheet 10: Installer Code Programming
Section Data
Description
(Default Setting: 000000)
[1000] ___/___/___/___/___/___ Installer code (refer to section [3001], in Worksheet 20 on page 40)
