System Options | 41
WARNING: In option 5 of section [3030], a 40 VA transformer is required when selecting the 850 mA battery charge current. Using a 20 VA transformer
with a battery charge current of 850 mA may damage the system.
NOTE: For instructions on wiring a panel for tamper recognition, refer to the Digiplex Evo Installation Guide (available online only).
Section [3033]
System Options 3
1 Multiple actions in user menu Disabled
Enabled
Section [3034]
System Options 4
1 & 2
Wireless Transmitter Supervision
Options (refer to Table 28 on page
41)
Refer to
Table 28 on
page 41
Refer to
Table 28 on
page 41
2 User code length Fixed
Flexible
3
User code length (if option 2
is OFF)
4 digits
6 digits 3
Generate supervision failure if
detected on a bypassed
wireless zone
Yes
No
4Power save mode
Disabled Enabled 4
Restrict arming on a wireless
transmitter supervision failure
Disabled
Enabled
5
Bypass not displayed while system
is armed
Disabled Enabled
5 & 6
Zone & Module Tamper
Recognition Options
(refer to Table 29 on page 41)
Refer to
Table 29 on
page 41
Refer to
Table 29 on
page 41
6Trouble latch Disabled
Enabled
7 EOL resistor on hardwire zones Disabled
Manually 7
Generate tamper if detected on
bypass zone
Yes No
8Zone doubling (ATZ) Disabled
Enabled 8 Restrict arming on tamper trouble Disabled
Enabled
Section [3035]
System Options 5
1 Restrict arming on AC failure Disabled
Enabled
= Default
* When the combus speed is changed, all operations on the system will be suspended for
approximately one minute, while the system adjusts itself.
** This option is used by certain event monitoring softwares, such as Hyperterminal. With
BabyWare and printers, it is always being transmitted.
2 Restrict arming on battery failure Disabled
Enabled
3
Restrict arming on bell or auxiliary
failure
Disabled
Enabled
4 Restrict arming on TLM failure Disabled
Enabled
5
Restrict arming on module
troubles
Disabled
Enabled
6 Account number transmission Partition #
Tel #
7
Transmit zone status on
serial port**
Disabled
Enabled
8 Serial port baud rate
38,400 57,600
Table 28: Wireless Transmitter Supervision Options; Options 1 and 2 for Section [3034]
Option
Description
1 2
OFF OFF Disabled (default)
OFF ON Generates trouble only (when armed or disarmed)
ON OFF
When armed: follows zone types (refer to Zone Programming on page 10)
When disarmed: generates trouble only
ON ON
When armed: follows zone types (refer to Zone Programming on page 10)
When disarmed: generates audible alarm
Table 29: Zone and Module Tamper Recognition Options; Options 5 and 6 for Section [3034]
Option
Description
5 6
OFF OFF Disabled (default)
OFF ON Generates trouble only (when armed or disarmed)
ON OFF
When armed: follows zone types (refer to Zone Programming on page 10) for zone tamper;
generates trouble for module tamper
When disarmed: generates trouble only
ON ON
When armed: follows zone types (refer to Zone Programming on page 10)
When disarmed: generates audible alarm
Table 27: Description of Sections [3029] to [3035] (Continued)
Section Option Description OFF ON Section Option Description OFF ON
To Next Page
